YAMAHA DTX MULTI 12 w/ MAT1

Built-in pads: 12
External inputs: 5 (One 3-zone input, 4 monaural inputs)
Maximum polyphony: 64 notes
Wave memory: 100 MB (16-bit linear conversion)
Drum and percussion voices: 1,061
Keyboard voices: 216
Preset drum kits: 50
User-defined kits: 200
Effects: 42 types of Variation; 6 types of Chorus; 6 types of Reverb; 5-band master equalizer
Pad functions: Increment or decrement of drum kit, pattern, or tempo; tap tempo; switching on or off of click-track; transmission of control change messages

Waves:
Readable quantity: 500
Bit depth: 16 bit
Wave memory: 64 MB
Maximum size: Mono sample: 2 MB
Stereo sample: 4 MB
Sample formats: Proprietary, WAV, and AIFF
Sequence capacity: 152,000 notes
Note resolution: Quarter note / 480
Recording method: Realtime overdubbing
Preset patterns: 128 phrases (including 3 demo patterns)
User-defined patterns: 50 phrases
Sequence formats: Proprietary
SMF Format 0 (for loading only)

Click-track features:
Tempo: 30 to 300 BPM. Tap tempo functionality
Beats: 1/4 – 16/4, 1/8 – 16/8, 1/16 – 16/16
Note timing: Accent notes, quarter notes, eight notes, sixteenth notes, triplets
Connectors: Pad 13 jack (standard stereo-phone plug; left = trigger, right = rim switch);
Pad 14/15 and Pad 16/17 jacks (standard stereo-phone plug; left = trigger, right = trigger)
Hi-hat control jack (standard stereo-phone plug)
Foot switch jack (standard stereo-phone plug)
Output L/Mono and R jacks (standard phone plugs)
